Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
100
HCD-FL3
CD DOOR CD DOOR SW1 CD DOOR SW2
CD MOTOR CENTER SW AMP
< SWITCH >
S341 1-477-173-11 ENCODER (VOLUME)
**************************************************************
1-684-204-11 CD DOOR SW1 BOARD
******************
< SWITCH >
S331 1-571-300-21 SWITCH, LEVER SLIDE
(CD DOOR OPEN/CLOSE DETECT)
**************************************************************
1-684-205-11 CD DOOR SW2 BOARD
******************
< SWITCH >
S332 1-771-821-11 SWITCH, PUSH (1 KEY)
(CD DOOR LOCK DETECT)
**************************************************************
1-684-202-11 CD MOTOR BOARD
****************
< CAPACITOR >
C303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C304 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C305 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN309 1-569-909-11 SOCKET, CONNECTOR 15P
CN312 1-565-856-11 SOCKET, CONNECTOR 8P
CN313 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
CN314 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D305 8-719-976-99 DIODE UDZ-TE-17-5.1B
< IC >
IC302 8-759-598-69 IC BA6956AN
< RESISTOR >
R315 1-216-805-11 METAL CHIP 47 5% 1/10W
R316 1-216-817-11 METAL CHIP 470 5% 1/10W
**************************************************************
A-4676-869-A CENTER SW AMP BOARD, COMPLETE
(E2, E51, AR, MX)
A-4728-428-A CENTER SW AMP BOARD, COMPLETE
(AUS, SP)
****************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-162-290-31 CERAMIC 470PF 10% 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C504 1-126-965-11 ELECT 22uF 20% 50V
C505 1-136-165-00 FILM 0.1uF 5% 50V
C506 1-136-165-00 FILM 0.1uF 5% 50V
C507 1-128-560-11 ELECT 22uF 20% 100V
C508 1-128-560-11 ELECT 22uF 20% 100V
C520 1-162-294-31 CERAMIC 0.001uF 10% 50V
C521 1-128-562-11 ELECT 47uF 20% 100V
C522 1-126-967-11 ELECT 47uF 20% 50V
C551 1-126-964-11 ELECT 10uF 20% 50V
C552 1-162-290-31 CERAMIC 470PF 10% 50V
C553 1-162-282-31 CERAMIC 100PF 10% 50V
C554 1-104-665-11 ELECT 100uF 20% 10V
C555 1-136-165-00 FILM 0.1uF 5% 50V
C556 1-136-165-00 FILM 0.1uF 5% 50V
C591 1-130-777-00 FILM 0.1uF 5% 100V
C592 1-130-777-00 FILM 0.1uF 5% 100V
C593 1-135-928-21 ELECT 2200uF 20% 63V
(SP, AUS)
C593 1-137-840-11 ELECT 2200uF 20% 63V
(E2, E51, MX, AR)
C594 1-135-928-21 ELECT 2200uF 20% 63V
(SP, AUS)
C594 1-137-840-11 ELECT 2200uF 20% 63V
(E2, E51, MX, AR)
C921 1-130-483-00 MYLAR 0.01uF 5% 50V
C922 1-130-483-00 MYLAR 0.01uF 5% 50V
C923 1-126-944-11 ELECT 3300uF 20% 25V
C927 1-126-964-11 ELECT 10uF 20% 50V
C928 1-126-926-11 ELECT 1000uF 20% 10V
< CONNECTOR >
CN502 1-573-826-11 CONNECTOR, BOARD TO BOARD 12P
* CN503 1-766-719-11 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D501 8-719-911-19 DIODE 1SS133T-72
D502 8-719-911-19 DIODE 1SS133T-72
D520 8-719-911-19 DIODE 1SS133T-72
D521 8-719-911-19 DIODE 1SS133T-72
D551 8-719-911-19 DIODE 1SS133T-72
D552 8-719-911-19 DIODE 1SS133T-72
D591 6-500-249-01 DIODE D15XB20
D921 8-719-028-23 DIODE D3SBA20-4101
< IC >
IC501 8-749-017-16 IC STK442-130
IC922 8-759-701-59 IC TA7809S
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q521 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q522 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q523 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W
R502 1-249-437-11 CARBON 47K 5% 1/4W
R503 1-249-415-11 CARBON 680 5% 1/4W
R504 1-249-437-11 CARBON 47K 5% 1/4W
0 R505 1-245-233-11 METAL 0.22 10% 5W F
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
