Sony HCD-FL3 - Page 99

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
99
HCD-FL3
BD BLUE LED CD DOOR
Q102 8-729-920-85 TRANSISTOR 2SD1664-T100-QR
< RESISTOR >
R101 1-216-821-11 METAL CHIP 1K 5% 1/10W
R102 1-216-845-11 METAL CHIP 100K 5% 1/10W
R103 1-216-835-11 METAL CHIP 15K 5% 1/10W
R104 1-216-839-11 METAL CHIP 33K 5% 1/10W
R105 1-216-821-11 METAL CHIP 1K 5% 1/10W
R106 1-216-821-11 METAL CHIP 1K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R109 1-216-857-11 METAL CHIP 1M 5% 1/10W
R111 1-216-846-11 METAL CHIP 120K 5% 1/10W
R114 1-218-745-11 RES-CHIP 160K 5% 1/10W
R116 1-216-001-00 METAL CHIP 10 5% 1/10W
R117 1-216-821-11 METAL CHIP 1K 5% 1/10W
R118 1-216-809-11 METAL CHIP 100 5% 1/10W
R119 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R120 1-216-835-11 METAL CHIP 15K 5% 1/10W
R122 1-216-845-11 METAL CHIP 100K 5% 1/10W
R123 1-216-833-11 METAL CHIP 10K 5% 1/10W
R124 1-216-845-11 METAL CHIP 100K 5% 1/10W
R131 1-216-813-11 METAL CHIP 220 5% 1/10W
R143 1-216-839-11 METAL CHIP 33K 5% 1/10W
R144 1-216-839-11 METAL CHIP 33K 5% 1/10W
R147 1-218-701-11 RES-CHIP 2.4K 5% 1/10W
R148 1-216-797-11 METAL CHIP 10 5% 1/10W
R149 1-216-797-11 METAL CHIP 10 5% 1/10W
R158 1-216-838-11 METAL CHIP 27K 5% 1/10W
R159 1-216-838-11 METAL CHIP 27K 5% 1/10W
R162 1-216-845-11 METAL CHIP 100K 5% 1/10W
R171 1-216-837-11 METAL CHIP 22K 5% 1/10W
R172 1-216-837-11 METAL CHIP 22K 5% 1/10W
R173 1-216-837-11 METAL CHIP 22K 5% 1/10W
R181 1-216-837-11 METAL CHIP 22K 5% 1/10W
R182 1-216-837-11 METAL CHIP 22K 5% 1/10W
R183 1-216-837-11 METAL CHIP 22K 5% 1/10W
R190 1-216-813-11 METAL CHIP 220 5% 1/10W
R191 1-216-839-11 METAL CHIP 33K 5% 1/10W
R192 1-216-839-11 METAL CHIP 33K 5% 1/10W
R193 1-216-846-11 METAL CHIP 120K 5% 1/10W
R194 1-216-839-11 METAL CHIP 33K 5% 1/10W
R195 1-216-849-11 METAL CHIP 220K 5% 1/10W
R196 1-216-819-11 METAL CHIP 680 5% 1/10W
R198 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< VARIABLE RESISTOR >
RV101 1-238-602-11 RES, ADJ, CARBON 47K
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
1-684-201-11 BLUE LED BOARD
**************
< CAPACITOR >
C316 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
< LED >
D308 LED SELU5E23C-
(NULTI CHANNEL DECODING)
< RESISTOR >
R381 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R382 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R383 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R384 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R385 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R386 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R387 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R388 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
**************************************************************
1-684-203-11 CD DOOR BOARD
**************
< CAPACITOR >
C341 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C342 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C343 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN317 1-565-856-11 SOCKET, CONNECTOR 8P
< LED >
D341 8-719-071-41 LED SELS5923C-TP15 (DISC 1 INDICATOR)
D342 8-719-071-41 LED SELS5923C-TP15 (DISC 2 INDICATOR)
D343 8-719-071-41 LED SELS5923C-TP15 (DISC 3 INDICATOR)
D344 8-719-071-41 LED SELS5923C-TP15 (DISC 4 INDICATOR)
D345 8-719-071-41 LED SELS5923C-TP15 (DISC 5 INDICATOR)
< SHORT >
JR341 1-216-864-11 SHORT CHIP 0
JR342 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R333 1-216-864-11 SHORT CHIP 0
R334 1-216-864-11 SHORT CHIP 0
R335 1-216-864-11 SHORT CHIP 0
R336 1-216-864-11 SHORT CHIP 0
R337 1-216-864-11 SHORT CHIP 0
R341 1-216-797-11 METAL CHIP 10 5% 1/10W
R342 1-216-809-11 METAL CHIP 100 5% 1/10W
R343 1-216-809-11 METAL CHIP 100 5% 1/10W
R344 1-216-809-11 METAL CHIP 100 5% 1/10W
R345 1-216-809-11 METAL CHIP 100 5% 1/10W
R346 1-216-809-11 METAL CHIP 100 5% 1/10W
