Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
40
HCD-FL3
DSP
C791 1-126-934-11 ELECT 220uF 20% 10V
C792 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C793 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN601 1-569-928-11 SOCKET, CONNECTOR 11P
* CN602 1-569-935-11 SOCKET, CONNECTOR 19P
CN702 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE) 7P
CN703 1-785-335-11 PIN, CONNECTOR (LIGHT ANGLE) 9P
< DIODE >
D601 8-719-083-89 DIODE 11ES2N-TB5
D606 8-719-988-61 DIODE 1SS355TE-17
D611 8-719-988-61 DIODE 1SS355TE-17
D612 8-719-988-61 DIODE 1SS355TE-17
D741 8-719-988-61 DIODE 1SS355TE-17
D742 8-719-988-61 DIODE 1SS355TE-17
< GROUND TERMINAL >
EP601 1-537-738-21 TERMINAL, EARTH
EP602 1-537-738-21 TERMINAL, EARTH
< SHORT/FERRITE BEAD >
FB601 1-216-864-11 SHORT CHIP 0 (EXCEPT AUS)
FB601 1-414-772-11 FERRITE 0uH (AUS)
FB602 1-414-772-11 FERRITE 0uH (AUS)
FB611 1-216-864-11 SHORT CHIP 0
FB702 1-216-864-11 SHORT CHIP 0
FB703 1-216-864-11 SHORT CHIP 0
FB704 1-216-295-00 SHORT CHIP 0
FB708 1-216-864-11 SHORT CHIP 0 (EXCEPT AUS)
FB710 1-216-864-11 SHORT CHIP 0 (EXCEPT AUS)
FB711 1-216-864-11 SHORT CHIP 0 (EXCEPT AUS)
< IC >
IC601 6-702-009-01 IC CXD9720Q
IC602 8-759-538-16 IC IS61LV6416-10TT (ISSI)
IC603 6-702-008-01 IC LC89057W-VF4-E
IC611 8-759-560-56 IC PCM1800E/2K
IC612 6-702-007-01 IC PCM1608Y/2K
IC621 8-749-019-26 IC TORX141 (OPTICAL DIGITAL IN)
IC622 8-749-019-25 IC TOTX141 (OPTICAL DIGITAL OUT)
IC631 8-759-835-63 IC NJM2391DL1-26 (TE1)
IC701 6-702-010-01 IC M61520FP
IC702 8-759-448-71 IC BU4053BCFV-E2
IC703 8-759-697-21 IC NJM4565V (TE2)
IC704 8-759-697-21 IC NJM4565V (TE2)
< JACK >
J701 1-766-396-11 JACK, PIN 4P (MD (VIDEO))
< RESISTOR/FERRITE BEAD >
JR602 1-216-864-11 SHORT CHIP 0 (EXCEPT AUS)
JR603 1-216-864-11 SHORT CHIP 0
JR604 1-216-864-11 SHORT CHIP 0
JR605 1-216-864-11 SHORT CHIP 0
JR611 1-216-864-11 SHORT CHIP 0
JR612 1-216-864-11 SHORT CHIP 0
JR613 1-216-864-11 SHORT CHIP 0
JR614 1-216-864-11 SHORT CHIP 0
JR615 1-216-864-11 SHORT CHIP 0
JR616 1-216-809-11 RES-CHIP 100 5% 1/10W
JR621 1-216-864-11 SHORT CHIP 0
JR622 1-216-864-11 SHORT CHIP 0
JR623 1-216-864-11 SHORT CHIP 0
JR624 1-216-864-11 SHORT CHIP 0
JR625 1-216-864-11 SHORT CHIP 0
JR640 1-216-864-11 SHORT CHIP 0
JR642 1-216-864-11 SHORT CHIP 0
JR644 1-216-864-11 SHORT CHIP 0
JR645 1-216-864-11 SHORT CHIP 0
JR646 1-216-864-11 SHORT CHIP 0
JR647 1-216-864-11 SHORT CHIP 0
JR651 1-216-864-11 SHORT CHIP 0
JR652 1-216-864-11 SHORT CHIP 0
JR653 1-216-864-11 SHORT CHIP 0
JR654 1-216-864-11 SHORT CHIP 0
JR655 1-216-864-11 SHORT CHIP 0
JR662 1-216-864-11 SHORT CHIP 0
JR663 1-216-864-11 SHORT CHIP 0
JR671 1-216-864-11 SHORT CHIP 0
JR672 1-216-864-11 SHORT CHIP 0
JR701 1-216-864-11 SHORT CHIP 0
JR702 1-216-864-11 SHORT CHIP 0
JR706 1-216-295-00 SHORT CHIP 0
JR707 1-164-360-11 CERAMIC CHIP 0.1uF 16V
(AUS)
JR709 1-216-864-11 SHORT CHIP 0 (AUS)
JR710 1-414-772-11 FERRITE 0uH (AUS)
JR711 1-216-864-11 SHORT CHIP 0 (AUS)
JR741 1-216-864-11 SHORT CHIP 0
< COIL >
L701 1-414-170-11 INDUCTOR 100uH
L702 1-414-170-11 INDUCTOR 100uH
L703 1-414-170-11 INDUCTOR 100uH
L704 1-414-170-11 INDUCTOR 100uH
L751 1-414-170-11 INDUCTOR 100uH
L752 1-414-170-11 INDUCTOR 100uH
L753 1-414-170-11 INDUCTOR 100uH
L754 1-414-170-11 INDUCTOR 100uH
< TRANSISTOR >
Q601 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q602 8-729-113-66 TRANSISTOR FN1L4M-T1M31
Q701 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q702 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q703 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q704 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q710 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q711 8-729-805-43 TRANSISTOR FA1F4M-T1L32
Q751 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q752 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q753 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
