Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
48
HCD-FL3
< LED >
D301 8-719-058-04 LED SEL5223S-TP15 (I/1)
D302 8-719-071-41 LED SELS5923C-TP15 (CD)
D303 8-719-071-41 LED SELS5923C-TP15 (TUNER/BAND)
D304 8-719-071-41 LED SELS5923C-TP15 (TAPE A/B)
< IC >
IC301 6-600-071-01 IC TSOP7000
< RESISTOR >
R301 1-216-813-11 RES-CHIP 220 5% 1/10W
R302 1-216-809-11 RES-CHIP 100 5% 1/10W
R303 1-216-809-11 RES-CHIP 100 5% 1/10W
R304 1-216-809-11 RES-CHIP 100 5% 1/10W
R305 1-216-819-11 RES-CHIP 680 5% 1/10W
R306 1-216-821-11 RES-CHIP 1K 5% 1/10W
R307 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R308 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R309 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
R313 1-216-805-11 RES-CHIP 47 5% 1/10W
R314 1-216-805-11 RES-CHIP 47 5% 1/10W
< SWITCH >
S301 1-771-410-21 SWITCH, TACTILE (I/1)
S302 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S303 1-771-410-21 SWITCH, TACTILE (CD)
S304 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S305 1-771-410-21 SWITCH, TACTILE (TAPE A/B)
S306 1-771-410-21 SWITCH, TACTILE (DIGITAL)
S307 1-771-410-21 SWITCH, TACTILE (MD (VIDEO))
**************************************************************
A-4728-403-A PANEL (R) BOARD, COMPLETE
*************************
< CAPACITOR >
C313 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< JACK >
J301 1-815-603-11 JACK (PHONES)
< RESISTOR >
R321 1-216-819-11 RES-CHIP 680 5% 1/10W
R322 1-216-821-11 RES-CHIP 1K 5% 1/10W
R323 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R324 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R325 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
R326 1-216-827-11 RES-CHIP 3.3K 5% 1/10W
R327 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R328 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R329 1-216-819-11 RES-CHIP 680 5% 1/10W
R330 1-216-821-11 RES-CHIP 1K 5% 1/10W
R331 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R332 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
< SWITCH >
S311 1-771-410-21 SWITCH, TACTILE (DISC SELECT)
S312 1-771-410-21 SWITCH, TACTILE (Z)
S313 1-771-410-21 SWITCH, TACTILE (gG)
S314 1-771-410-21 SWITCH, TACTILE (X)
S315 1-771-410-21 SWITCH, TACTILE (x)
S316 1-771-410-21 SWITCH, TACTILE (.)
S317 1-771-410-21 SWITCH, TACTILE (>)
S318 1-771-410-21 SWITCH, TACTILE (– m)
S319 1-771-410-21 SWITCH, TACTILE (M +)
S320 1-771-410-21 SWITCH, TACTILE (GROOVE)
S321 1-771-410-21 SWITCH, TACTILE (EFFECT)
S322 1-771-410-21 SWITCH, TACTILE (CD SYNC, HI-DUB)
S323 1-771-410-21 SWITCH, TACTILE (REC, PAUSE/START)
S324 1-771-410-21 SWITCH, TACTILE (Z B)
**************************************************************
1-684-271-11 REGULATOR BOARD
*****************
< CAPACITOR >
C870 1-115-867-11 ELECT 0.1uF 20% 50V
C871 1-115-867-11 ELECT 0.1uF 20% 50V
C872 1-115-867-11 ELECT 0.1uF 20% 50V
C873 1-115-867-11 ELECT 0.1uF 20% 50V
C878 1-126-791-11 ELECT 10uF 20% 16V
C879 1-126-791-11 ELECT 10uF 20% 16V
C880 1-126-791-11 ELECT 10uF 20% 16V
C881 1-126-791-11 ELECT 10uF 20% 16V
< IC >
IC801 6-701-760-01 IC UPC3504AHF
IC802 8-759-231-53 IC TA7805S
IC803 8-759-231-57 IC TA7810S
IC804 8-759-231-53 IC TA7805S
< TRANSISTOR >
Q864 8-729-040-20 TRANSISTOR RT1P137L-TP
Q865 8-729-116-02 TRANSISTOR BA1A4M-TP
< RESISTOR >
R873 1-216-864-11 SHORT CHIP 0
R887 1-216-809-11 RES-CHIP 100 5% 1/10W
**************************************************************
A-4728-436-A SP RELAY BOARD, COMPLETE
*************************
< CAPACITOR >
C1 1-126-947-11 ELECT 47uF 20% 16V
C2 1-130-483-00 MYLAR 0.01uF 5% 50V
C4 1-136-165-00 FILM 0.1uF 5% 50V
C6 1-126-960-11 ELECT 1uF 20% 50V
C7 1-126-961-11 ELECT 2.2uF 20% 50V
C8 1-126-964-11 ELECT 10uF 20% 50V
C9 1-126-960-11 ELECT 1uF 20% 50V
C10 1-126-964-11 ELECT 10uF 20% 50V
C11 1-126-960-11 ELECT 1uF 20% 50V
C12 1-126-960-11 ELECT 1uF 20% 50V
PANEL (L) PANEL (R) REGULATOR SP RELAY
