Setup for the Whole System / Network Settings / Setting the Signal Format
Chapter
Chapter 16 System Setup
16
System Setup
Setup for the Whole
System
Carry out operations relating to setup for the whole system
in the Engineering Setup menu.
Here the “whole system” refers to all devices connected on
the system switcher LAN.
Setting the unit ID
In addition, the switcher processor and control panel are all
tied to unit ID of 1.
For more details of how to make the unit ID settings, refer
to the installation manual for the particular device.
Network Settings
This provides automatic configuration of all devices
connected to the switcher system LAN, and displays a list
of them.
Setting the Group ID
1
In the Engineering Setup >System >Network Config
menu (7311), press [Group ID].
2
Enter a number (1 to 8) in the pop-up menu, and press
[Enter].
3
Check the message, then press [Yes].
Authenticating the IP Address
Automatically
1
In the Engineering Setup >System >Network Config
menu (7311), press [Auto Config].
Devices with the same group ID within the network
are detected and displayed.
2
Check the message, then press [Yes].
3
To register the list of detected devices as the setting
values at power-on, press [Define].
4
Check the message, then press [Yes].
Setting the Signal Format
After changing any of the following settings, be sure to
press [Execute] (or [FC Format Execute] for changing the
format converter signal format) to save the new values.
When you press [Execute], some data is lost (such as frame
memory images).
If you press [FC Format Execute], this data is not lost.
Setting the Signal Format
Specify the signal format to be handled by the devices.
The combinations of signal formats that can be selected are
as follows.
1
In the Engineering Setup >System >Format menu
(7313), select the device for operations.
Notes
System Field frequency Effective number of
scan lines
HD system 50 1080i
59.94
23.976 1080PsF
24
50 720P
59.94
SD system 59.94 480i
50 576i
