Cross-Point Settings
Chapter 17 Control Panel Setup
The functions of the buttons in the memory recall
section during effect editing are on two pages; to set
the functions of buttons on the second page, press the
[2] button in the <PageSelect> group in the button
area.
• Buttons in the memory recall section during
macro editing
5 Press [Set] to confirm the setting.
To cancel an assignment
Select the corresponding button, then press [Clear].
To return all button assignments to the factory
default state
Press [Default].
Cross-Point Settings
Creating Cross-Point Assign Tables
As cross-point assign tables, you can create a “main” table
and up to 14 other tables (table 1 to table 14). However,
you can only carry out assignment of the video and key
combinations in the main table.
Creating the main table
In the main table, a pair consisting of a video signal and a
key signal is assigned to each button number. You can also
assign the same signal to another button number at the
same time. Further, you can delete currently assigned
signals from the main table.
1 In the Engineering Setup >Panel >Xpt Assign menu
(7322) or Engineering Setup >Panel >Xpt Assign
>Table Button Assign menu (7322.1), press [Main, V/
K Pair Assign].
The Main, V/K Pair Assign menu (7322.5) appears.
The left of the status area shows the video and key
signal names, and source number currently assigned in
the main table. On the right is a list of the source
numbers and signals that can be assigned. When the
shift button is pressed, the number column is
distinguished by color.
2 Select the button number.
3 When assigning a video signal, press [Video] in the
<Assign> group. When assigning a key signal, press
[Key]. (You can select a video signal and a key signal
at the same time.)
[Video] and [Key] in the <Assign> group cannot be
turned off at the same time. One or the other is always
on.
4 Select the signal.
“IN33” to “IN48” and signal names relating to DME
and M/E-2 are disabled, even if selected.
5 Using the buttons in the <Xpt Assign> group, assign
the selected signal to the button number currently
selected in the main table.
Copy COPY
Paste PSTE
Select all ALL
Insert INS
Modify MOD
Delete DEL
Keyframe loop count setting KF LOOP
Effect duration setting EFF DUR
Keyframe duration setting KF DUR
Delay setting DLY
Constant duration mode on or off CNST DUR
Go to specified timecode GOTO TC
Go to specified keyframe GOTO KF
Set range FROM TO
Return the button display to that
before effect was executed
EXIT
Switch to numeric keypad input
mode
STOR
Go to first keyframe REWIND
Switch to shifted functions SHFT
Go to previous keyframe <<PREV
Go to next keyframe >>NEXT
Execute effect RUN
Function Button indication
Undo UNDO
Pause setting PAUS
Auto insert mode on or off AUTO INS
Copy COPY
Paste PSTE
Select all ALL
Insert INS
Modify MOD
Delete DEL
Set range FROM TO
Go to specified event GOTO EVNT
Function Button indication
Notes
