228
Setting Button Assignments
Chapter 17 Control Panel Setup
If Shotbox Recall is selected: Select the shotbox
register you want to assign.
4 Press [Action Set].
To cancel an assignment
Select the button, then press [Clear].
To display register names in the Utility Command
column
If in step 2 you select [Macro Recall] or [Shotbox Recall],
press the [Reg Name Display] button to select whether or
not register names appear in the Utility Command column.
List of utility commands and user preference button status
The following table shows the utility commands that can
be assigned to user preference buttons.
No. Parameter Adjustment
3 Macro Macro register selection
No. Parameter Adjustment
3 Shotbox Shotbox register selection
Command name
a)
Function Button status
Lit amber Off
SWR RemoteS1 Enbl
SWR RemoteS2 Enbl
Switcher Remote S1 enabled/disabled
Switcher Remote S2 enabled/disabled
Enabled Disabled
ME1 PGM1 ST
|
ME1 PGM4 ST
M/E-1 PGM1 output safe title on/off
|
M/E-1 PGM4 output safe title on/off
On Off
ME1 PVW ST M/E-1 preview output safe title on/off On Off
ME1 Clean ST M/E-1 clean output safe title on/off On Off
ME1 K-PVW ST M/E-1 key preview output safe title on/
off
On Off
PP PGM1 ST
|
PP PGM4 ST
P/P PGM1 output safe title on/off
|
P/P PGM4 output safe title on/off
On Off
PP PVW ST P/P preview output safe title on/off On Off
PP Clean ST P/P clean output safe title on/off On Off
PP K-PVW ST P/P key preview output safe title on/off On Off
Edit PVW ST Edit preview output safe title on/off On Off
Preset ST Preset output safe title on/off On Off
AUX1 ST
|
AUX24 ST
AUX1 output safe title on/off
|
AUX24 output safe title on/off
On Off
FM Src1 Frame Freeze Frame freeze of frame memory source
1
During frame freeze Either of the other two
states
FM Src1 Filed Freeze Field freeze of frame memory source 1 During field freeze Either of the other two
states
FM Src1 Freeze Off Release freeze of frame memory
source 1
While freeze being
released
Either of the other two
states
FM Src2 Frame Freeze Frame freeze of frame memory source
2
During frame freeze Either of the other two
states
FM Src2 Field Freeze Field freeze of frame memory source 2 During field freeze Either of the other two
states
FM Src2 Freeze Off Release freeze of frame memory
source 2
While freeze being
released
Either of the other two
states
SWR GPI Enbl Enable/disable switcher GPI Enabled Disabled
Panel GPI Enbl Enable/disable panel GPI Enabled Disabled
