Sony RM-280 - Page 78

78
Setup Menu
The speed assigned to the search dial
Units: Speed (times)
26 ASM POST
(ASSEMBLE POSTROLL REC)
Sets the postroll recording time. To set the postroll time to 0 frames,
set it to –4FRM. If the postroll time is still not set to 0 frames, adjust
the value around –4FRM for fine adjustment.
[+3SEC], 2S, 1S, +1FRM to –9FRM
Note
This menu is effective only when an XDCAM device is connected.
(The postroll time is fixed to 3 seconds when a VTR is connected.)
27 XDC EDIT
(XDCAM ASM EDIT MODE)
Sets the assemble editing method when an XDCAM device is
connected.
[NORMAL]: Performs normal assemble editing.
NEW CLIP: Creates the new clip after the last clip of the XDCAM
1)
device connected as the recorder, simply by setting the IN and
OUT point of the player.
1) Supported devices: PDW-1500, PDW-F75, PDW-HR1, PDW-HR1/MK1,
PDW-HD1500, PDW-F1600, PDW-HD1200
Note
When any device other than an XDCAM device is connected, the
unit operates as NORMAL, even if NEW CLIP is set.
28 VAR RANG
(VAR RANG SPEED RANGE SETTING)
Assigns the search speed in the variable mode to the search dial.
When NORMAL is set, the search speed can be changed when the
VAR button is held down.
[NORMAL], –1 to +2, –1 to +1, –05 to +05
For details on the setting and assignable speeds, see “The speed
assigned to the search dial” (see page 78).
Note
When the setting is set to other than NORMAL, the search speed
can not be changed, even if the VAR button is held down.
40 VERSION
(VERSION DISPLAY)
Displays the software version of the unit.
41 RST MENU
(RESET MENU DATA)
Resets all the settings of the setup menu to factory setting.
RESET ON: Resets all the settings.
[OFF]: Doesn’t reset.
Item
number
Item name Settings
JOG
SHTL
VAR
–1 (–1) 1
–1 (–0.74) 2
–1 (–0.5) 3
–1 (–0.34) 4
–1 (–0.2) 5
–0.5 (–0.12) 6
–0.2 (–0.06) 7
qf +2 (+1)
qd +2 (+0.74)
qs +2 (+0.5)
qa +1.5 (+0.34)
0 +1 (+0.2)
9 +0.5 (+0.12)
8 +0.2 (+0.06)
Example) The search speed when NORMAL is set in menu item 28
Search dial
