Getting Started
Before connecting cords, make sure to disconnect the AC power cord (mains lead).
AFront speaker A (L)
BFront speaker A (R)
CCenter speaker
DSubwoofer
b)
ESurround back speaker (L)
c)
FSurround back speaker (R)
c)
GSurround speaker (L)
HSurround speaker (R)
a)
If you have an additional front speaker
system, connect them to the FRONT
SPEAKERS B terminals. You can select
the front speaker system you want to use
with the SPEAKERS switch (OFF/A/B/
A+B) on the front panel (page 50).
Connecting speakers
HG F
BAD
E
C
A
B
FRONT SPEAKERS
B terminals
a)
A Monaural audio cord (not supplied)
B Speaker cords (not supplied)
BB
B
continued
