Getting Started
The following illustration shows how to connect a component which has analog jacks such as a
DVD recorder or VCR, etc.
It is not necessary to connect all the cables. Connect audio and video cords according to the jacks
of your components.
Connecting components with analog video and audio jack
DVD recorder, VCR
AB
Audio signals Video signals
A Audio cord (not supplied)
B Video cord (not supplied)
continued
To Next Page
