• Waveforms
– AUDIO Board – – DISPLAY Board –
qa
Q105, 106 (Base)
1 V/DIV, 5 Ps/DIV
10.4 Ps
2.8 Vp-p
qs
Q105, 106 (Collector)
20 V/DIV, 5 Ps/DIV
10.5 Ps
40.8 Vp-p
40.2 ns
4.1 Vp-p
1
IC2102 qd (MCKOUT)
2 V/DIV, 20 ns/DIV
20.8 Ps
4.1 Vp-p
3
IC2102 qg (LRCKOUT)
2 V/DIV, 10 Ps/DIV
4
IC2102 e; (XMCK)
1 V/DIV, 20 ns/DIV
40.2 ns
1.9 Vp-p
40 ns
3.9 Vp-p
5
IC2102 ea (XOUT)
2 V/DIV, 20 ns/DIV
7
IC2502 ok (BCLK_OUT)
2 V/DIV, 100 ns/DIV
326 ns
4.7 Vp-p
20.8 Ps
3.3 Vp-p
8
IC2502 ol (LRCLK_OUT)
1 V/DIV, 10 Ps/DIV
6
IC2502 wg (XTAL2)
1 V/DIV, 20 ns/DIV
39.4 ns
3.3 Vp-p
2
IC2102 qf (BCKOUT)
2 V/DIV, 100 ns/DIV
326 ns
4.3 Vp-p
