Square Wave Signal
The Square Wave Signal waveform has the following characteristics:
H Signal frequency: 1 MHz
H Waveform points: 200
H Clock frequency: 200 MHz
H Output parameters: Filter 50 MHz
H Equation: range(0,1ms)<LF>range(0,0.5ms)<LF>1<LF>
range(0.5ms,1ms)<LF>–1
Figure D-4: Square Wave Signal
