Sample Waveform Library
VX4792 User Manual
D-5
Ramp Signal
The Ramp Signal waveform has the following characteristics:
H Signal frequency: 1 MHz
H Waveform points: 200
H Clock frequency: 200 MHz
H Output parameters: Filter 20 MHz
H Equation: range(0,1ms)<LF>–1+2*x
 


Figure D-3: Ramp Signal
