Table E-2: Environmental Characteristics
Characteristics Performance Requirement
Temperature
Operating 0° C to +40° C
Nonoperating -20° C to +70° C
Humidity
0° C to +30° C 95% Relative Humidity
+30° C to +40° C 75% Relative Humidity
Altitude
Operating 3.05 km (10,000 feet)
Derate maximum operating temperature -1° C for every 300 m (1,000 feet) above 1.5 km
(5,000 feet)
Nonoperating 4.57 km (15,000 feet)
Vibration Withstands 0.33 mm (0.013 inches)
pĆp
, 5 Hz to 55 Hz sinewave, 15 minutes each axis,
10 minutes each axis at resonance or 55 Hz
Shock Withstands 30 g (half sine), 11 ms duration, 3 shocks in each direction along 3 major
axes, 18 total shocks
Packaged Product Vibration and Shock Qualified under National Safe Transit Association Preshipment Test Procedures 1AĆBĆ1
and 1AĆBĆ2
Table E-3: Mechanical Characteristics
Characteristics Performance Requirement
Module Size DĆsize, Double wide (requires two slots in the mainframe)
Overall Dimensions
Height 262 mm (10.3 in)
Width 61 mm (2.4 in)
Depth 368 mm (14.5 in)
Weight
Net 3 kg (6.7 lbs)
Shipping 3.5 kg (7.7 lbs)
Cooling 5 l/s @ 0.5 mm H
2
Ofora10° C rise (average of two slots)
The temperature rises are generally different depending on the left slot part or the right
slot part in this module. When using the VX1410 as a mainframe, they are specified to;
15 ° C rise in the left slot part and 7 ° C rise in the right slot part.
