Specifications
E-6
VX4792 User Manual
Table E-1: Electrical Characteristics (Cont.)
Characteristics Supplemental InformationPerformance Requirement
Clock
Amplitude 1 V"0.3 V into 50 W
Impedance 50 W typical
Auxiliary Inputs
Trigger
Threshold
Range -5 V to +5 V
Resolution 0.1 V
Accuracy "(5% of Level + 0.1 V)
Pulse Width 15 ns Minimum
Input Swing 0.2 V Minimum
Input Voltage 10 V
pĆp
with 1 MW Impedance
5 V
RMS
with 50 W Impedance
Impedance 1 MW with 30 pF maximum capacitance, or
50 W
Trigger→Signal Delay
Internal Clock 50 ns typical
External Clock 50 ns+1clockcycleistypical
Trigger Holdoff t1ms Maximum
(Excluding Auto Step mode)
AM
Range 2 V
pĆp
(-1 V to +1 V) for 100% Modulation "5%
Input Voltage "5 V Maximum
Impedance 10 kW typical
Clock
Threshold Level 0.5 V"0.1 V
Pulse Width 2 ns Minimum
Input Swing 0.8 V Minimum
Input Voltage "2 V Maximum
Impedance 50 W typical
Frequency Range Up to 250 MHz
To Next Page
