Specifications
VX4792 User Manual
E-5
Table E-1: Electrical Characteristics (Cont.)
Characteristics Supplemental InformationPerformance Requirement
Filters
3 dB Cutoff Frequency
1 MHz
5 MHz
20 MHz
50 MHz
1 MHz "20%
5 MHz "20%
20 MHz "20%
50 MHz "20%
Delay
1 MHz
5 MHz
20 MHz
50 MHz
390 ns typical
78 ns typical
18 ns typical
11 ns typical
Characteristics Low pass filter with Bessel characteristics
Auxiliary Outputs
Sync
Amplitude u1.2 V into 50 W
u2.4 V into open circuit
Impedance 50 W typical
Duration 100 ns "20%
Sync→Signal Delay 10 ns typical
Marker 1
Amplitude 2.5V (+5%/-10%) into 50 W
5V (+5%/-10%) into open circuit
Rise/Fall Time t8 ns
Impedance 50 W typical
Marker→Signal Delay 10 ns typical
Marker 2
Amplitude 2.5V (+5%/-10%) into 50 W
5V (+5%/-10%) into open circuit
Rise/Fall Time t8 ns
Impedance 50 W typical
Marker→Signal Delay 10 ns typical
