VX4792 User Manual
Table E-1: Electrical Characteristics (Cont.)
Characteristics Supplemental InformationPerformance Requirement
Operating Mode The trigger source can be an external
signal, a VXI trigger from the resource
manager, or a trigger command from the
resource manager
Continuous Generates a waveform or sequence
continuously
Triggered Generates a waveform or sequence once
when triggered
Burst Generates a waveform or sequence for a
specified burst count time when triggered
Gated Generates a waveform or sequence
continuously while the external trigger
signal is true, or after receiving a or
command
Waveform Advance Generates waveforms defined in the
sequence file continuously; a trigger signal
advances to the next waveform within the
sequence file
Autostep Generates waveforms or sequences
defined in the autostep file once when
triggered; a trigger signal advances to the
next waveform or sequence within the
autostep file, which may include new
output parameters (for example, new
amplitude or offset settings)
Arithmetic Operation
AM
Sensitivity 2 V
pĆp
(5%) Signal Produces 100%
Modulation
100% modulation at +1 V
50% modulation at 0 V
0% modulation at -1 V
Frequency Response DC to 4 MHz -3 dB
