Performance Verification
VX4792 User Manual
F-3
Prerequisites
The tests in this section comprise an extensive, valid confirmation of perfor-
mance and functionality, when the following requirements are met:
H The waveform generator must be operating as an integral part of an
appropriately configured mainframe
H The operating conditions must comply with those specified for the system
mainframe in which the waveform generator is installed
H The test environment must comply with the limits described in Table E–2
Environmental Characteristics
H The waveform generator must have been calibrated at an ambient tempera-
ture between +20_ C to +30_ C following a 20 minute warm up period
H The waveform generator must be operating for at least 20 minutes before the
tests are performed
Equipment Required
The performance verification procedures have been written using the test
equipment listed in Table F–1. If alternate equipment is used, the equipment
must meet or exceed the minimum requirements shown in Table F–1.
Table F-1: Test Equipment Requirements
Item Description Minimum Requirements Recommended Instrument
Oscilloscope Bandwidth: 350ĂMHz
Two channels
1
Tektronix TDS500 Series Digitizing
Oscilloscope or 2400 Series Digitizing
Oscilloscope
Function Generator Output voltage: -5ĂV to +5ĂV Tektronix FG 5010 Programmable Function
Generator
2
Frequency Counter Frequency range: 10ĂHz to 250ĂMHz
Accuracy: ±10 ppm
Tektronix DC 5010 Programmable UniverĆ
sal Counter/Timer
2
Digital Multimeter (DMM) DC volts range: 0.05ĂV to +5ĂV
Accuracy: ±0.1%
Fluke 8842A
TM 5000 Series Power Module 6 plugĆin slots Tektronix TM 5006A Power Module
VXIbus Mainframe CĆsize Tektronix VX1410
VXIbus Resource Manager CĆsize slot 0 resource manager Tektronix VX4521
Personal Computer IBM PC/AT compatible IBM PC, PC XT, PC AT, or PCĆcompatible
computer
1
Four channels are recommended when performing the Synchronous Operation Checks.
2
Requires a TM 5000 Series Power Module.
