Selecting a DME Channel (Menu)
This section describes the M/E-1 key 1 menu as an
example.
1 Open the Home > M/E-1 > Key1 > Resizer/Proc Key
> Resizer Adjust/DME Select menu (11101.41).
2 In the [DME Select] group, select a DME channel
(DME 1 to DME 4) to assign.
You can check the DME chann
el status using the
button display.
On: DM
E channel assigned to the selected key
Off:
DME channel not assigned
Lock icon: DME channel
assigned to a different key/
bus
To select a DME channel assigned to a different
key or
bus
Use the override function. You can release the DME
channel
assignment for another key/bus and then select
the DME channel.
To enable the override function, set the [O
verride] button
to the on state.
The DME channel is assigned to the selected key and the
lock icon
displayed on the DME channel button
disappears.
Using two to four DME channels on a
single key
You can select multiple consecutive DME channels.
1 Open the Home > M/E-1 > Key1 > Resizer/Proc Key
> Resizer Adjust/DME Select menu (11101.41).
2 In the [DME Select] group, select a DME channel
(DME 1 to DME 4) to assign.
When using two DME channels
Set the [DME 1] button and [DME 2] button, the
[DME 2]
button and [DME 3] button, or the [DME 3]
button and [DME 4] button to the on state.
When using three DME channels
Set the [DME 1] button, [DME 2] button, and [DME
3] b
utton, or the [DME 2] button, [DME 3] button,
and [DME 4] button to the on state.
When using four DME channels
Set the [DME 1] button, [DME 2] button, [DME 3]
bu
tton, and [DME 4] button to the on state.
Selecting a DME channel signal
Select the following signals on
the 1st channel to 4th
channel.
For details about selecting a signal, see “Chapter 4
Selecting Signals” (page 80).
1st channel signal: Key bus signal
2nd channel signal: DME external video bus signal
3rd channel signal: DME utility 1 bus signal
4th channel signal: DME utility 2 bus signal
Assigning to DME monitor outputs
1 Open the Home > M/E-1 > Key1 > Resizer/Proc Key
> Monitor menu (11101.44).
2 Set the [Monitor Set] button to the on state.
3 In the [DME Select] group, select a DME channel
(DME 1 to DME 4) to assign.
Only DME channels assigned t
o the selected key can
be selected.
The output of the selected DME channel
is assigned
to the monitor output (DME MON V and DME MON
K), and the [Monitor Set] button switches to the off
state.
Selecting a DME Channel (Key
Control Block)
This section describes an example using a DME on key 1
on M/E-1.
1 Press the [M/E-1] button, turning it on.
2 Press the [KEY1] button, turning it on.
3 Select a DME channel to assign using the DME
channel selection buttons (DME1 to DME4).
You can check the DM
E channel status using the lit
color of the [DME1] button to [DME4] button.
Lit green: DME channel
assigned to the selected key
Off: DM
E channel not assigned
Lit amber: DM
E channel assigned to a different key/
bus
To select a DME channel assigned to a different
key or
bus
Use the override function. You can release the DME
ch
annel assignment for another key/bus and then select
the DME channel.
To enable the override function, press and hold the
[OVER
RIDE] button and press a DME channel selection
button that is lit amber.
The DME channel is assigned to t
he selected key and the
color of the DME channel selection button changes to
green.
