Sony XVS-G1

410
Setting a Router
Assigning a Destination
You can assign a destination to a cross-point (destination
selection delegation button).
You can set a source table and operation inhibit settings
for ea
ch destination.
• A source table cannot be selec
ted on buttons with
button numbers 65 to 128.
• Operation inhibit cannot be configured for buttons with
bu
tton numbers 65 to 128.
• On the ICP-X7000, the 1st row/2nd row of the AUX
bu
s control block (router operation mode) are used as
destination selection delegation buttons.
1 Open the Home > Setup > Panel > Router >
Delegation Button Assign menu (19104.51).
A list of delegation buttons to which to assign a
d
estination is shown on the left and a list of
assignable destinations is shown on the right.
2 In the list on the left, select the target button to set.
You can also press the [Select
Button] button and
enter a button number in the numeric keypad window.
3 In the list on the right, select a destination to assign.
You can also press the [Sele
ct Destination] button
and enter a destination number in the numeric keypad
window.
4 Press the [Set] button.
To select a source table
Select the target button to set
and select a source table
(Table 1 to Table 5) in the [Source Table] group.
To inhibit operation of buttons
Select the target button and set
the [Inhibit] button to the
on state.
Setting the operation mode of the shift
button
You can set the operation mode of the [SHIFT] button
assigned to the right edge of a delegation button row (1st
row/2nd row) in the AUX bus control block (router
operation mode).
1 Open the Home > Setup > Panel > Router >
Delegation Button Assign menu (19104.51).
2 In the [Destination Shift Mode] group, select an
operation mode.
Hold: Enable
the destination in the shifted state of the
delegation buttons while pressing the shift
button.
Lock: Swit
ch the destination between the shifted
state and unshifted state of the delegation buttons
each time the shift button is pressed.
Setting the recall target for a snapshot
You can set whether a destination is the recall target when
a snapshot of the router is recalled.
When operation inhibit is enabled, destination recall is
not avail
able.
1 Open the Home > Setup > Panel > Router >
Delegation Button Assign menu (19104.51).
2 In the list on the left, select the target button to set.
You can also press the [Select Button
] button and
enter a button number in the numeric keypad window.
3 Set the [Snapshot Enable] button to the on state.
Assigning a Source Table
You can set five types of source table.
You can assign a source to a cross-point (source selection
cross-
point button) for each source table.
On the ICP-X7000, the 3rd row/4th row of the AUX bus
con
trol block (router operation mode) is used as source
selection cross-point buttons.
1 Open the Home > Setup > Panel > Router > Source
Table Assign menu (19104.52).
2 Display the target source table to set.
Select a tab to change the source table (Src Table1 to
Src Table5) to
display.
A list of delegation buttons
to which to assign a
source is shown on the left and a list of assignable
sources is shown on the right.
3 In the list on the left, select the target button to set.
You can also press the [Select Button
] button and
enter a button number in the numeric keypad window.
