114
Fade-to-Black
This function gradually darkens the image and changes
the P/P program output image to black.
When the switcher bank operation mode is multi
-program
mode, multi program 2 mode, or DSK mode, fade-to-
black is executed for multiple program outputs
simultaneously.
You can also disable fade-to-black for each program
ou
tput.
For details, see “Enabling/Disabling Fade-To-Black”
(page 391).
Setting Fade-to-Black
Assigning a utility command
To execute fade-to-black, the “Fade To Black” utility
command must be assigned to the following buttons
beforehand.
• Memory recall buttons in the utility/shotbox control
blo
ck
• Memory recall buttons in the utility control block
• Cross-point buttons in the cross-point control block
For details about assigning a utility command, see
“Assigning a utility command” (page 400).
Setting the transition rate
1
Open the Home > P/P > Bus/Transition > Transition
> Transition Type menu (11909.21).
2
Press the [FTB] button and enter a transition rate in
the numeric keypad window.
To set the transition rate in list view
You can set the fade-to-black transiti
on rate in transition
rate list view on each switcher bank.
1
Open the Home > Utility > Transition Rate menu
(18201.21).
2
Press the [FTB] button and enter a transition rate in
the numeric keypad window.
Executing Fade-to-Black
This section describes operation using a memory recall
button ([FTB] button) in the utility/shotbox control block
or utility control block assigned with the “Fade To Black”
utility command.
1
Select a bank.
For details about selecting a bank in the utility/
shotbox
control block, see “Selecting a bank”
(page 235).
In the utility control block, press the [UTIL/SBOX]
button to swi
tch the memory recall section to utility/
shotbox operation mode and select a bank.
For details about selecting a bank in the utility
control block,
see “Selecting a bank” (page 236).
2
Press the [FTB] button.
This executes fade-to-black with the preset transition
ra
te.
During the transition execution,
the [FTB] button is
lit light purple.
When the transition is comple
ted, the image becomes
black and the [FTB] button color changes to red.
Note
