437
Setting a Key Link
Setting a Transition Link
You can link the transition operations between keys.
The following operations are linked.
• Auto transition in an independent key transition
• Key on/off in an independent key transition
1
Open the Home > Setup > Link > Key Transition
Link > Link in Single M/E menu (19107.31).
2
Display the target switcher bank to set.
Select a tab to change the swit
cher bank to display.
3
Select the target key to set.
4
Enable/disable the link using the [Link Enable]
switch.
On: Ena
ble link.
Off: Di
sable link.
5
Press the [Edit] button for [Linked Key].
The [Linked Key] window appears.
6
Place a check mark in a link destination key.
You can set multiple keys.
7
Press [OK].
To link the key selection of a next transition
Set the [Next Trans. Link] button to the on state.
The keys are linked and the next transition selection
butt
ons in the transition control block are selected.
Example:
When key 2 and key 3 are linked to key 1:
When key 1 is selected in a next transition, key 2 and key
3 are
also selected.
The link setting of the next transiti
on selection buttons is
common to all switcher banks.
Linking independent key transitions
between M/Es
You can link the key operations between switcher banks.
The following operations are linked.
• Auto transition in an independent key transition
• Key on/off in an independent key transition
1
Open the Home > Setup > Link > Key Transition
Link > Link in Multi M/Es menu (19107.32).
2
Select the target link number to set.
To select and set multiple link numbers, place a check
m
ark beside the target link numbers to set.
To select and set all link numbers, place a check mark
in
the Select All checkbox.
3
Enable/disable the link using the [Link Enable]
switch.
On: Enable
link.
Off: Disable
link.
4
Press the [Edit] button for [Controlling Key].
The [Assign Controlling Key] window appears.
5
Set the button for the link source key to the on state.
6
Press [OK].
7
Press the [Edit] button for [Linked Key].
The [Assign Linked Key] window appears.
8
Set the button for the link destination key to the on
state.
9
Press [OK].
Note
