Chapter
233
Other Functions
Utility Functions
The utility functions assign a specific function (action) to
a button for recall when the button is pressed.
You can assign the following a
ctions to the memory recall
buttons in the utility/shotbox control block, the memory
recall buttons in the utility control block, and the cross-
point buttons in the cross-point control block.
• Utility command
• Recalling a macro register
• Recalling a shotbox register
• Menu shortcut
For details about assi
gnment, see “Assigning a Utility
Function” (page 400).
To use the menu shortcut function, the control panel must
be
linked with the menu.
For details, see “Linking a Control Panel with the Menu”
(page 76).
Status of buttons assigned with an action
When a button is set to the on state (when the action is
executed), the status of the button changes as described
below.
The status of a button assigne
d with a utility command
depends on the command.
For details, see “Status of buttons assigned with a utility
command” (page 235).
Memory recall buttons in the utility/sh
otbox
control block and utility control block
When a macro register recall or shot
box register recall is
assigned:
On: Lit orange
Off: Lit dark
blue
For an empty register, gray characters are displayed
on
black.
When a menu shortcut is assigned:
On: Lit light
purple
Off: Li
t purple
Cross-point buttons in the cross-point control
block
On: Lit ambe
r
Off: Not lit
Note
