438
Setting a Color Corrector
Link Group
You can configure an AUX bus color corrector link
group.
1
Open the Home > Setup > Link > Aux Bus CCR Link
menu (19107.41).
2
Select the target AUX bus to set.
To select and set multiple AUX buses, place a check
mar
k beside the target AUX buses to set.
To select and set all AUX buses, place a check mark
i
n the Select All checkbox.
3
Press the [Link Group] button and select a group
(Link 1 to Link 12) from the pull-down list.
AUX buses configured in the same group form a link
g
roup.
Setting a Bus and
Destination Link
You can link a switcher bus with a router destination.
Setting a Matrix
You can set the first source address, first destination
address, and level of a matrix to set in NS-Bus space.
You can set up to eight types of matrix.
1
Open the Home > Setup > Link > External Bus Link
> Matrix Settings menu (19107.51).
2
Select the target matrix to set.
3
Press the [Source] button and enter a source address
in the numeric keypad window.
4
Press the [Destination] button and enter a destination
address in the numeric keypad window.
5
Press the [Level] button and select a level (1 to 8) to
set from the pull-down list.
Setting a Bus
You can select a matrix and link a switcher bus with a
router destination.
1
Open the Home > Setup > Link > External Bus Link
> Bus/Destination Assign menu (19107.52).
2
Select the target link number to set.
To select and set multiple link numbers, place a check
m
ark beside the target link numbers to set.
To select and set all link numbers, place a check mark
in
the Select All checkbox.
3
Press the [Edit] button for [Controlling Bus].
The [Controlling Bus] window appears.
4
Set the button for the link source bus to the on state.
Select a tab to change the bus to display.
[M/E-1 to M/E-5] tab: M/
E bus
[P/P] tab: P/P bus
[Aux] tab: AUX
bus
[FM/DME Util] tab: Frame
memory/DME bus
5
Press [OK].
