Keyframe fader
Press the [KF] button, turning i
t on, in the transition
control block/transition control block (simple type) on the
ICP-X7000.
You can execute an effect timeline manually by
co
nfiguring a fader lever as a keyframe fader and using
the fader lever.
• The [KF] button must be assigned to the transition
co
ntrol block/transition control block (simple type)
beforehand.
For details about assign
ing buttons, see “Assigning
Control Panel Buttons” (page 397).
• Multiple fader levers cannot be simultaneously used as
keyframe faders
. Only the last configured fader lever is
enabled.
• When a macro attachment is set for a fader lever, the
mac
ro cannot be executed while the fader lever is used
as a keyframe fader.
Executing an Effect Timeline
(Device Control Block)
You can operate a recalled effect timeline using the Z-
ring in the device control block.
Run control operation mode
Press the [RUN CTRL] button in the device control block
to
switch to run control operation mode.
In run control operation mode, you can exe
cute an effect
timeline manually using the Z-ring.
Clockwise rotation: Executes from the
first keyframe to
the last keyframe.
Counterclockwise rotation: Executes from the last
keyf
rame to the first keyframe.
Device control block display
In the device control block of the ICP-X7000, the display
sh
ows the following information.
• Reference region name
• Register number and register name
• DUR: Effect duration (minute:second:f
rame)
• KF: Current keyframe number, total number of
keyframes, and current timecode
(hour:minute:second:frame)
Effect Timeline Register
Operations
Displaying an Effect Timeline
Register
Displaying a multi region effect timeline
register
Open the Home > Register > Effect Timeline > Edit
Register > Browse Multi Rgn menu (18301.31).
You can check the following information.
[Region] group region display:
Displays the region selection status.
The selected regions are displayed in white
ch
aracters, and the reference region is displayed
highlighted.
List on the left:
Displays a list of registers for the selected
regions.
•Register number
• Reference region register name
• Number of regions for which data is saved in the
register
• Lock icon
A lock icon is displayed when the reference region
regi
ster is locked.
List on the right:
Displays information for each region about the
re
gister selected in the list on the left.
• Region name
The reference region is displayed highlighted.
•Register name
• Lock icon
A lock icon is displayed when a
register is locked.
When the [Browse Single Rgn] button is pressed, the
Home
> Register > Effect Timeline > Edit Register >
Browse Single Rgn menu (18301.32) is recalled.
For details, see “Displaying a single region effect
timeline register” (page 277).
To select a region
1
Press the [Select] button in the [Region] group.
The [Select Region] window appears.
2
Set the button for the target region to the on state.
You can select multiple regions.
Select a tab to change the region to display.
[ME] tab:
Switcher bank regions
[User] tab: U
ser regions
[DME] tab: DME
regions
Notes
