166
Setting a DME Wipe
DME wipe patterns and modifiers are configured using
the menu.
This section describes the M/E-1 menu as an example.
Setting a DME Wipe Pattern
Selecting a DME wipe pattern
1
Open the DME wipe pattern selection menu.
In 1-channel mode, open the Home
> M/E-1 > Bus/
Transition > DME Wipe > 1ch Pattern menu
(11109.41).
In 2-channel mode, open the Home
> M/E-1 > Bus/
Transition > DME Wipe > 2ch Pattern menu
(11109.42).
In 3-channel mode, open the Home
> M/E-1 > Bus/
Transition > DME Wipe > 3ch Pattern menu
(11109.43).
2
Press the button for a DME wipe pattern group.
The patterns in the selected gr
oup are displayed.
For 1-channel mode
Select from the following DME wipe pattern groups.
Slide / Squeeze: Slide
and squeeze
Split / Door: Sp
lit and door
Flip Tumble: Fl
ip tumble
Page Turn: Page turn
Roll: Ro
ll
Frame I/O / P in P: Fr
ame in/out and picture-in-
Mosaic / Defocus: Mo
saic and defocus
Resizer Slide / Squeeze: Resiz
er slide and squeeze
Resizer Frame I/O:
Resizer frame in/out
For 2-channel mode
Select from the following DME wipe pattern groups.
Slide / Squeeze: Slide
and squeeze
P in P: Pict
ure-in-picture
Crop Slide: Cr
op slide
Page Turn: Page turn
Roll: Ro
ll
Frame I/O: Frame i
n/out
Brick: Br
ick
For 3-channel mode
Select from the following DME wipe pattern groups.
Brick: Br
ick
3
Set the button for the target DME wipe pattern to the
on state.
Adjusting DME wipe pattern parameters
When the following patterns are selected, set the
parameters.
Squeeze (1-channel mode) pattern numbers
103
2, 1033
Crop Slide (2-channel mode) pattern numbers
266
1, 2662
a) Set relative to a transition start point of 0% and end point of 100%.
Page Turn (1-channel mode) pattern numbers
1301 to 1313, 1315 to 1318, 1341 to 1345
Page Turn (2-channel mode) pattern numbers
270
1 to 2713, 2715 to 2718, 2741 to 2745
Roll (1-channel mode) pattern numbers 1321 to
133
3, 1335 to 1338, 1346 to 1350
Roll (2-channel mode) pattern numbers 2721 to
273
3, 2735 to 2738, 2746 to 2750
a) 0% is an effect like a turned page, 100% is normal curl, and 200% is
radius with double the normal curl.
b) –100.00 is rotation in the counterclock
wise direction, +100.00 is rotation
in the clockwise direction, and 0.00 is no rotation.
Brick (2-channel mode) pattern numbers 2801 to
2804, 2811 to 2814
a) Side V image horizontal center position. At –100.00, the center is at the
left edge of the screen. At +100.00, the center is at the right edge of the
screen.
b) Side V image vertical center position. At –100.00, the center is at the
b
ottom edge of the screen. At +100.00, the center is at the top edge of the
screen.
Frame I/O (2-channel mode) pattern numbers
2851 to 2854
No. Parameter Adjustment
1 Holding Level Position for entering the dead
band
a)
2 Tolerance Width of the dead band
No. Parameter Adjustment
1 Radius Radius of the turned page flap/
ro
lled-up portion
a)
2 Magnitude Angle of rotation through course
of transition
b)
3 Start Angle Angle at start of transition
b)
No. Parameter Adjustment
1 Side V Size X Side V horizontal scaling factor
2 Side V Size Y Side V vertical scaling factor
3 Height Height of brick
4 Center X Horizontal center position
a)
5 Center Y Vertical center position
b)
No. Parameter Adjustment
1 Delay Timing for image selected on a
uti
lity bus to enter the frame
