433
Setting a Parallel Tally
You can set the output port for a parallel tally.
1
Open the Home > Setup > Router/Tally > Tally >
Parallel Tally menu (19106.26).
2
Select the target parallel output port to set.
To select and set multiple ports, place a check mark
beside
the target ports to set.
To select and set all ports, pla
ce a check mark in the
Select All checkbox.
You can also press the [Sele
ct Number(s)] button and
enter a port number in the numeric keypad window.
Ports on boards 2 and 3 can be used when an
XKS-G17
00 Legacy Interface Board (option) is
installed.
3
Press the [Tally Assign] button and select a type of
tally from the pull-down list.
Src Tally: Set
source tally. Return a tally to the
sources that are output to the destinations.
Dest Tally: Set desti
nation tally. Return a tally to the
destinations outputting sources that return a tally
using source tally.
To set a source tally
1
Select the target parallel output port to set.
2
Press the [Source] button and enter a source address
in the numeric keypad window.
3
Press the [Edit] button for [Tally Type].
The [Select Tally Type] window appears.
4
Set the button for the target tally to the on state.
R1 to R8: T
ally type 1 to 8 for red tally
G1 to G8:
Tally type 1 to 8 for green tally
Y1 to Y8: Tally
type 1 to 8 for yellow tally
5
Press [OK].
To set a destination tally
1
Select the target parallel output port to set.
2
Press the [Destination] button and enter a destination
address in the numeric keypad window.
3
Press the [Level] button and enter a level (1 to 8) in
the numeric keypad window.
4
Press the [Edit] button for [Tally Type].
The [Select Tally Typ
e] window appears.
5
Set the button for the target tally to the on state.
R1 to R8:
Tally type 1 to 8 for red tally
G1 to G8: Ta
lly type 1 to 8 for green tally
Y1 to Y8:
Tally type 1 to 8 for yellow tally
6
Press [OK].
To delete a paralle
l tally setting
Select the target parallel tally to delete and press the
[Clear] button.
Note
