Sony XVS-G1

235
a) Applies only to output signals assigned in the Home > Setup > System >
Output > Output Assign menu (19101.41).
b) Cannot be assigned to cross-point buttons in the cross-point control
blo
ck.
c) Linked to the key preview 1 setting
in the Home > Setup > Switcher >
Config > K-PVW Config menu (19103.14).
d) The target key menu (last recalled menu
) is displayed when a button
assigned with a utility command is double-pressed.
Status of buttons assigned with a utility command
Executing a Utility Function (Utility/
Shotbox Control Block)
You can perform utility function operations using the
memory recall section in the utility/shotbox control
block.
Press a memory recall button assi
gned with an action to
execute the utility function.
When using two utility/shotbox co
ntrol blocks, the action
assignments are common to both.
Selecting a bank
A group comprising the 24 butt
ons of the memory recall
section are called a “bank.”
There are 20 banks (1 to 20), and you select the target
bu
tton for operation by switching the bank.
Press a [BANK1] to [BANK20] button to switch the
memory recall section to func
tion recall mode for the
selected bank.
By default, bank 1 to 6 selection buttons are assigned.
To use bank 7 to 20, the bank 7 to 20 selection buttons
must be assigned
to assignable buttons beforehand.
AUTO PVW Auto preview
Preset PVW Preset preview
M/E-x Preview M/E-x preview
x = 1 to 5
P/P Preview P/P preview
M/E-x Sub Preview M/E-x preview on the sub side in multi program 2 mode
x = 1 to 5
P/P Sub Preview P/P preview on the sub side in multi program 2 mode
M/E-x K-PVW1
M/E-x K-PVW2
M/E-x key preview 1/key preview 2
x = 1 to 5
P/P K-PVW1
P/P K-PVW2
P/P key preview 1/key preview 2
M/E-x Key1 to 8 Preview
b) c) d)
M/E-x key 1 to key 8, key preview
x = 1 to 5
P/P Key1 to 8 Preview
b) c) d)
P/P key 1 to key 8, key preview
Command Function
Command Utility control block Cross-point control block
On Off On Off
GPI 1 to 50 Test Fire
Macro Cancel
Macro All Cancel
Flashes light purple
onl
y at the moment the
button is pressed
Lit purple Flashes amber only at
the moment the button
is pressed
Not lit
Pre Macro
Post Macro
Lit orange while the
button is pressed
Lit dark blue Lit amber while the
bu
tton is pressed
Not lit
Macro Take
Macro All Take
Lit purple during macro
pau
se
(Gray characters
displayed on black
w
hen the button is
disabled)
Lit light purple during
m
acro execution
Lit amber during macro
pause
Not lit during macro
execution
FTB Lit light purple, then lit
red whe
n execution
ends
Lit purple Lit amber, then lit red
when execution ends
Not lit
Other commands Lit orange Lit dark blue Lit amber Not lit
Note
Note
