159
Normal/Reverse: Alternate directions between
normal and reverse after each transition.
Reverse:
Wipe in the opposite direction of the
normal direction.
Softening the wipe pattern edge (Soft
edge)
Softens the edges of a pattern.
1 Open the Home > M/E-1 > Key1 > Transition > Wipe
menu (11101.52).
2 Set the [Soft] button to the on state and set the
following parameter.
Setting the wipe pattern position
(Position)
You can move a wipe pattern to a desired position.
1 Open the Home > M/E-1 > Key1 > Transition > Wipe
menu (11101.52).
2 Set the [Position] button to the on state and set the
following parameters.
To return a pattern from a moved position to the
center of the screen as a transition progresses
Set the [Auto Center] button to the on state.
Rotating a wipe pattern (Rotation)
1 Open the Home > M/E-1 > Key1 > Transition > Wipe
menu (11101.52).
2 In the [Rotation] group, select a rotation type.
Angle: Wip
e with a pattern at a fixed angle.
Speed: Rota
te a pattern at a fixed speed.
Magnitude: Rotat
e a pattern through the specified
angle in a single transition.
When the [Angle] button is sel
ected, set the following
parameter.
When the [Speed] button is selected, set the following
parameter.
When the [Magnitude] button
is selected, set the
following parameters.
No. Parameter Adjustment
1 Soft Edge softness
No. Parameter Adjustment
1 Position H Horizontal position
• Negative values move left.
• Positive values move right.
2 Position V Vertical position
• Negative values move
down.
• Positive values move up.
No. Parameter Adjustment
1 Angle Inclination angle of pattern
• A value of –100.00
corresponds to a rotation of
one turn counterclockwise.
• A value of +100.00
correspon
ds to a rotation of
one turn clockwise.
• A value of 0.00
correspon
ds to no rotation.
No. Parameter Adjustment
1 Speed Rotation speed of pattern
• A value of –100.00
correspon
ds to 1 revolution/
second counterclockwise
rotation.
• A value of +100.00
correspon
ds to 1 revolution/
second clockwise rotation.
• A value of 0.00
correspon
ds to no rotation
(stationary).
No. Parameter Adjustment
1 Angle Angle of pattern at start of
transition
• A value of –100.00
correspon
ds to a rotation of
one turn counterclockwise.
• A value of +100.00
correspon
ds to a rotation of
one turn clockwise.
• A value of 0.00
correspon
ds to no rotation.
2 Magnitude Angle of rotation through
course
of transition
• A value of –200.00
correspon
ds to a rotation of
two turns counterclockwise.
• A value of +200.00
correspon
ds to a rotation of
two turns clockwise.
• A value of 0.00
correspon
ds to no rotation.
