Sony XVS-G1

248
Setting the Image Effect Function
This section describes the M/E-1 menu as an example.
Assigning a DME channel to a
background bus
Only one DME channel can be used on each background
bus.
1 Open the Home > M/E-1 > Bus/Transition > Bus >
Image Effect menu (11109.12).
2 In the [Image Effect] group, select the target
background bus to set.
Background A: Backgr
ound A bus
Background B: Ba
ckground B bus
3 In the [DME Select] group, select a DME channel
(DME 1 to DME 4) to assign.
You can check the DME chann
el status using the
button display.
On: DM
E channel assigned to the selected
background bus
Off:
DME channel not assigned
Lock icon: DME channel
assigned to a different key/
bus
To select a DME channel assigned to a different
key or
bus
Use the override function. You can release the DME
channel
assignment for another key/bus and then select
the DME channel.
To enable the override function, set the [O
verride] button
to the on state.
The DME channel is assigned to t
he selected background
bus and the lock icon displayed on the DME channel
button disappears.
Executing the Image Effect
Function
The image effect function can be executed on the cross-
point control block of the target switcher bank.
The DME effect to use for the image effect function must
be
configured for the DME channel beforehand.
This section describes the background A bus as an
exampl
e.
The button used to execute the image effect function must
be a
ssigned to the cross-point pad/function button section
of the cross-point control block beforehand.
For details about assigning buttons in the
cross-point
pad, see “Setting a Cross-Point Pad” (page 405).
For details about assigning buttons in the function button
sec
tion, see “Assigning Control Panel Buttons”
(page 397).
1 Press the [IMAGE] button, turning it on.
Use the [IMAGE] button for t
he cross-point button
row assigned with the background A bus.
2 Select a signal on the background A bus.
The signal set by the DME effect is output.
