Pause playback
Playback
Move to video playback stop point
Move to end of video content
[Variable Speed] button
[Set Loop Playback] button
Setting M/E Split
You can split an M/E hardware block (physical M/E
block) of the switcher for use as two sub blocks.
You can assign a logical M/E to each sub block.
For details about assignin
g a logical M/E, see “Assigning
a logical M/E” (page 384).
• Enabling M/E split will disable multi program 2 mode.
• When M/E split is enabled, t
he Out5 to Out8 outputs
cannot be used.
• When M/E split is enabled, the keys that can be used in
a single physical switcher block can be assigned
to the
two sub blocks. You can set the number of keys to
assign.
For details about setting keys, see “Setting sub block
keys” (page 384).
1 Open the Home > Setup > System > Format/Config >
M/E Split menu (19101.24).
2 Select the target physical M/E block to set.
3 Set the [M/E Split] switch to the on state.
To disable M/E split, set the [M
/E Split] switch to the
off state.
4 Press the [Apply] button.
To return to the previous setting
Press the [Clear] button.
5 Check the message, then press [OK].
The switcher system reboots.
Setting a GPU
The DME and SL key functions use a GPU.
When the system signal format is 21
60P, either the DME
function or SL key function can be enabled.
To use the DME and SL key functions, the XKS-G1600
GPU Pac
k (option) must be installed.
To use the DME function, the XZS-G1610 3D DME
Li
cense (option) is required. To use the SL key function,
the XZS-G1620 SL Key License (option) is required.
1 Open the Home > Setup > System > Format/Config >
GPU Config menu (19101.25).
2 In the [GPU Config] group, select a function to
enable.
DME: Enable
DME.
SL Key:
Enable SL key.
3 Press the [Apply] button.
To return to the previous setting
Press the [Clear] button.
4 Check the message, then press [OK].
The switcher system reboots.
Setting DME Channel Enhanced
Function Mode
1 Open the Home > Setup > System > Format/Config >
GPU Config menu (19101.25).
2 Set enhanced function mode.
To set DME channel 1
In the [DME Channel 1] group, ena
ble/disable
enhanced function mode.
Enhanced: En
able enhanced function mode.
Normal: Disab
le enhanced function mode.
To set DME channel 2
In the [DME Channel 2] group, ena
ble/disable
enhanced function mode.
Enhanced: En
able enhanced function mode.
Normal: Disab
le enhanced function mode.
3 Press the [Apply] button.
To return to the previous setting
Press the [Clear] button.
4 Check the message, then press [OK].
The switcher system reboots.
