Setting a delegation button row
You can assign bus delegation buttons to the delegation
button rows (1st row/2nd row) in an AUX bus control
block.
1
Open the Home > Setup > Panel > Xpt Module > Key
Deleg/AUX Assign menu (19104.33).
2
Select the [AUX] tab.
A list of delegation buttons is shown on the left and a
list
of assignable buses is shown on the right.
3
In the list on the left, select the target button number
to set.
4
In the list on the right, select a bus to assign.
5
Press the [Set] button.
To inhibit operation
Select the target button number a
nd set the [AUX Deleg
Inhibit] button to the on state.
To return the assignment to the defaults
Press the [Default Recall] button, check the message, then
press [OK].
Setting the operation mode of the shift
button
You can set the operation mode of the [SHIFT] button
assigned to the right edge of a delegation button row (1st
row/2nd row) in the AUX bus control block.
1
Open the Home > Setup > Panel > Xpt Module > Key
Deleg/AUX Assign menu (19104.33).
2
Select the [AUX] tab.
3
In the [AUX Shift Mode] group, select an operation
mode.
Hold: Ena
ble the bus in the shifted state of the
delegation buttons while pressing the shift
button.
Lock: Switc
h the bus between the shifted state and
unshifted state of the delegation buttons each
time the shift button is pressed.
Setting Buttons and Indicators
Setting the on/off state of cross-point
indicators
Cross-point indicators light up in the source color of the
video signal assigned to buttons on the 3rd row in the
cross-point control block.
You can disable the cross-point indicators so that they do
not turn
on.
1
Open the Home > Setup > Panel > Xpt Module >
Operation Mode menu (19104.31).
2
Display the target switcher bank to set.
Select a tab to change the swit
cher bank to display.
3
Set the on/off state of cross-point indicators using the
[Xpt Indicator] button.
On: Lit
Off: Not
lit
Setting the color of cross-point buttons
You can set the color of the 3rd row/4th row cross-point
buttons.
1
Open the Home > Setup > Panel > Xpt Module >
Operation Mode menu (19104.31).
2
Display the target switcher bank to set.
Select a tab to change the swit
cher bank to display.
3
In the [Xpt Button Color] group, select a color.
Source Color: Li
ght up in the source color set for the
video signal.
For details about source color, see “Setting the
Source Color” (page 381).
White:
Light up white.
Setting the Display
You can set the information that appears on the display in
the cross-point control block/AUX bus control block.
The display items and format can be sel
ected for each of
six display modes.
1
Open the Home > Setup > Panel > Xpt Module >
Display Mode menu (19104.34).
