412
Local] button in the [Source/Dest Name] group is set to
the on state.
• When the [NS-Bus Name Link] button is set to the on
sta
te, the settings of all source names for the switcher
(including wiring traceback), not just in the Home >
Setup > Xpt Assign menu, are always replaced by the
NS-Bus alias name.
• To display the NS-Bus alias name on a multi viewer
su
bscreen, you must set the [NS-Bus Alias] button in
the [Source/Dest Name] group to the on state and set the
[NS-Bus Name Link] button to the on state.
1
Open the Home > Setup > Panel > Custom >
Operation Mode menu (19104.61).
2
Set the [NS-Bus Name Link] button to the on state.
3
Check the message, then press [OK].
Setting the Transition Operation
Buttons and Display Mode
Setting the transition rate display
1
Open the Home > Setup > Panel > Custom >
Operation Mode menu (19104.61).
2
In the [Trans Rate Display] group, select a display
mode.
Frame: Di
splay as number of frames.
Timecode: Displa
y as timecode.
Setting the operation when the [FTB]
button is pressed during fade-to-black
1
Open the Home > Setup > Panel > Custom >
Operation Mode menu (19104.61).
2
In the [FTB] group, select an operation mode.
Continue: Cont
inue the transition.
Cancel: C
ancel the transition and return to the
previous state before executing fade-to-black.
Setting the independent key transition,
auto transition execution button display
ICP-X7000 configuration
Enabled using the [AUTO TRANS] butt
on in the
independent key transition execution section of the
transition control block, independent key transition
control block, and key fader control block.
1
Open the Home > Setup > Panel > Custom >
Operation Mode menu (19104.61).
2
In the [Auto Trans Key On Status] group, select a
display mode.
Disable: L
it amber during transition execution, and
goes off at the end of the transition.
Enable: Lit gr
een during transition execution, and at
the end of the transition it is lit red if on-air or lit
amber if not on-air.
ICP-X1000 series configuration
Enabled using a [KEY1 TRANS] to [KEY8 TRANS]
b
utton in the independent key transition execution section
of the transition control block.
1
Open the Home > Setup > Panel > Custom >
Operation Mode menu (19104.61).
2
In the [Key Trans On Status] group, select a display
mode.
Disable: L
it amber during transition execution, and
goes off at the end of the transition.
Enable: Lit gr
een during transition execution, and at
the end of the transition it is lit red if on-air or lit
amber if not on-air.
Setting the operation when an auto
transition execution button is pressed
during an auto transition
ICP-X7000 configuration
Enabled using the [AUTO TRANS] butt
on in the
transition control block, independent key transition
control block, and key fader control block, and the
[TAKE] button in the transition control block (simple
type).
Notes
Note
Note
Note
