10.0: SETTINGS
SETTINGS
10.0: SETTINGS
GUI PERFORMANCE
FRAME RATE
FULL, 1/2, 13, 1/4
Choose the highest frame rate that your device can reproduce for best performance.
DISABLE RESCALING
ON, OFF
Enable/Disable display rescaling. Disable this if your display is struggling with GUI movements..
DISABLE LED METERS
OFF, ON
If you are using a slower CPU, you may wish to turn off the LED channel meters to reduce CPU usage.
LOCAL
MASTER LOCK
ON, OFF
When ON, the Master Channel fader is locked in place. Other parameters are still changeable.
HOLD FADER FOR FINE TUNING
OFF, ON
Allowfadernetuningmode.
METER QUANTISATION
OFF, ON
Choosebetweenquantisedmetering-ratherlikeanLEDbargraph-ornon-quantised(continuous).
FADERGLOW
OFF, THIN, NORM
Options for the coloured lines under the faders. 1. On, 2. Thin and 3. Off. These lines are handy to quickly
seewhichgroupoffadersyouareviewing(blueforFX,orangeforAUX,andsoon).
