4.2.2: VCA GROUPS

Ui24R User Manual

HOW TO ADD/REMOVE MEMBER CHANNELS

VCA channels are assigned via the pop menu accessible by holding down on the desiired channel. All

changes can be made through this menu.

VCA INDICATORS ON CHANNEL STRIP

Color indicator for channel virtual LCD panel turns green when VCA is engaged for that channel. Also the chan-

nel strip will display V1-6 in green depending on which VCA is engaged.

VCA MUTE

When mute is placed on a VCA master, all member channels are also muted.

STEREO LINK

Createandstereochannelfromtwomonochannels.Odd/even(L/R)pairsarelinked,soifyoulinkchannel2

(right),itwillcreateastereochannelwithchannel1(left).

RESET CHANNEL

Reset channel sends a channel back to its default setting.

VCA SPILL

By clicking on the Spill tab on the VCA channel strip, the user can expand the entire VCA spread for that

channel.

ASSIGN VCA

VCA Groups allow you to control groups of Input Channels from a single VCA Master. For example, you could

put the whole drum kit under the control of a single VCA Master, or if you have a multiple mics on a guitar cabi-

net you could set the ratios with individual channels and then create a Guitar VCA Master - move the VCA Mas-

terChannelandallGroupMemberlevelswillbe‘offset’fromcurrentlevelsbytheVCAMasterlevel.TheUi24R

isabletoassignVCA’sfromtheMETERSSubMenuorfromindividualChannelSub-Menu’s.
