SoundCraft Ui24R User Manual

3.4: PHONE NAVIGATION
SOFTWARE > PHONE NAVIGATION
3.4: PHONE NAVIGATION
The MIX screen is the default for the Ui software - You can navigate from there to other screens and
functions in a variety of ways. To access the Menu screen, press the NAV icon in the top right corner of the
screen. Press it again to return to the MIX screen.
Ui24R User Manual
NAV
Access the main menu screen
Wheninuse,theNAVbuttonchangestothe‘Return’icon.UsethistoreturntotheMIXscreen.
SHOWS / SNAPSHOTS
Access the Show and Snapshots load/save page.

SoundCraft Ui24R Specifications

General

Channels quantity	24 channels
Digital sound processing	- bit
Microphone in	Yes
Master (XLR) out	8
Line inputs (RCA)	1
Headphone connectivity	6.3 mm
Number of microphone inputs	10
Rack capacity	4U
Video capability	-
USB connector type	USB Type-A, USB Type-B
LED indicators	Wi-Fi
Built-in display	No

Weight and Dimensions

Package weight	13600 g
