Ui24R User Manual

5.6 PATCHING

LOCAL

The Patching screen enables the user to select either the input source 1-20 or L/R Line In for each channel.

By selecting CHANNEL/EDIT/PATCHING the user will be able to nominate the selected source for each

channel

OVERVIEW

The Overview Tab will give the user, at a glance, a full overview of the patches and connections that have

been set up. These can be edited on the overview screen with all changes being global

USB-A

2TrackorStereoUSBlescanbepatchedtoavailableslots1-22usingCHANNEL/EDIT/USB-A

USB-DAW

MultitrackUSBlescanbepatchedfromyourDAWtoavailableSlots1-32usingCHANNEL/EDIT/USB-

DAW

RESET

Reset will quickly reset the patch screen to its default setting..

PATCH 1:1

Patch 1:1 makes easy work of patching by creating a 1:1 connection of physical inputs to mixer channels

for all channels.

Patches can be set

up for Local inputs,

Multitrack USB A and

Multi-track USB-DAW

Quick reset and Patch

1:1 make setting and

resetting patches a

one touch solution.
