4.2: INPUT: MIX PAGE

CHANNELS > INPUT: GAIN PAGE

4.2: INPUT: MIX PAGE

Ui24R User Manual

MUTE

Turn off the audio signal of a channel

MUTEisanimmediateaudiooff,ratherthanhavingtoslidedownthefader(andremovesthepossibilityof

forgettingitsoriginalposition).TheMUTEbuttonmutesthechanneloutputtothemainstereobus.Itcan

alsomuteanauxoutput,dependingontheaux’sPREorPOSTstatus(postfaderauxwillbemuted).

SOLO

Solo this channel

The SOLO button is grey when not in use and yellow when operational. Press the SOLO button to only hear

the Soloed channel. In SETTINGS the SOLO button signal can be routed to the headphones or to the Mas-

teroutputs+headphones.Therearealsotwosolomodes:SOLO1(pressingaSOLObuttondeactivates

aprevioussolo)andSOLO+(solosarecumulativeanddonotcancelprevioussolos).NOTE:Ifthe‘AUX’

optionissetfortheHEADPHONESOUTparameter(SETTINGS),theheadphonesoutputwillnotreectthe

Solo selection.

Thedefaultroutingis‘PFL’(PreFadeListen.However,SoloscanbesettoAFL(AfterFaderListen)inthe

SOLOTYPEparameterinGLOBALSETTINGS(seesection10).

PAN / BALANCE

Adjust the Pan / Balance

CHANNEL DISPLAY

Numeric fader level and pan

Shows the input as a dB level. It also shows the Pan position for three seconds after the pan slider is

moved.

CHANNEL NAME

Channel sub menu access, channel name scrolling, channel select

The Channel Name is usually a name/description of that channel. You can click on channel names to select

that channel, double click/tap a channel name to go to the EDIT screen for that channel, or you can Long-

Click/Taponachannelnametoaccessthechannelsub-menu(Seesection4.3).
