4.0:2 Ui SIDE PANEL
The Ui Side panel is a multi-function interface that enables easy access to View and Mute Groups. The
expanded format has separate tabs for Banks, Media Player and Functions allowing even greater ac-
cessibility.
The Large format
Slideout Ui Strip
in Banks Mode
expands on the
standard slideout
strip with Smart
Scrolling through
the Ui display and
quick tabs to trans-
port the user to the
Start or End of the
display.
The Large format
Slideout Ui Strip
in Player mode al-
lows quick access
to Muliti-track
and 2-track USB
Playback and
Recording.
The Slim Slideout
Ui Strip displays
Inputs, FX Returns,
Sub Groups, AUX
Masters, View and
Mute Group Tabs.,
Tap Tempo, Mute
All, Mute FX and
More Me options.
Clicking on these
will open their
function screens
allowing the user
quick access.
All three Large format Ui Strips give easy access to View and Mute
Groups, Mute FX, Tap Tempo, FX Masters, AUX Masters, VCA
Masters and Sub Groups. The More Me function is accessed via a
tab in the Meters screen
The large format
Slideout Ui Strip
in Functions
Mode allows the
user access to
Save snapshot,
update current
snapshot, previ-
ous snapshot/
next snapshot
scrolling through
snapshots.
