Ui24R User Manual
5.1: DIGITECH
CHANNEL EDIT > DIGITECH
5.1: DIGITECH
DIGITECH ON/OFF
Turn DigiTech processing on or off
When DigiTech processing is turned off, the channel will revert to its standard input stage.
PRESETS
Open the PRESETS management pop-up
You can save and load settings presets for the DigiTech processing using this pop-up.
AMP CONTROLS
Adjust detailed settings for the selected amp model
The controls include GAIN, LEVEL, BASS, MID, and TREBLE. Use the GAIN control to overdrive the amp
model.
CHANNEL CONTROLS
Single view editing of selected input channel controls
Available input channel sections are: FX, High Pass Filter, Notch Filter, Compressor, Gate

SoundCraft Ui24R Specifications

General

Channels quantity	24 channels
Digital sound processing	- bit
Microphone in	Yes
Master (XLR) out	8
Line inputs (RCA)	1
Headphone connectivity	6.3 mm
Number of microphone inputs	10
Rack capacity	4U
Video capability	-
USB connector type	USB Type-A, USB Type-B
LED indicators	Wi-Fi
Built-in display	No

Weight and Dimensions

Package weight	13600 g
