4.2: INPUT: MIX PAGE

CHANNELS > INPUT: MIX PAGE

4.2: INPUT: MIX PAGE

Ui24R User Manual

TheMIXpageistheUicontrolsoftware’sdefaultpageandallowsyoutocontroltheroutingandpanning

and fader of a Ui input channel. Please note - the phone software displays panning/balance, solo, and mute

status, but for control you should use the EDIT page. Those controls are described in this section.

TABLET: Click/tap MIX/GAIN button to toggle MIX and GAIN pages.

PHONE: The RETURN button will always return you to the MIX page.

Adoubleclick/taponaGAINchannelstrip(notthefadercap)willreturnyoutotheMIXpage.

A double click/tap on a channel name will take you to the EDIT page for that channel.

FADER

Adjust the level of this channel in the master stereo mix.

METERING

VU metering for input level and volume level.

TheVUmetersontheMIXpageshowtwocolours.Thebluemetersshowtheinputgain(fromtheGAIN

page)andtheyellowmetersoverthetopshowthevolumelevel.Pleasenote,EQ&DYNaffectsthevolume

meters.
