4.1: INPUT: GAIN PAGE

Ui24R User Manual

PHANTOM POWER

Phantom Power is required to power certain microphones such as condenser microphones,

or other active

devices such as an active DI. It is activated per channel. You can get an overview of phan-

tompowerstatusintheMETERSscreen(blueindicator).

When phantom power is activated, the channel output is momentarily muted to avoid tran-

sients being

transmittedtotherestoftheaudiochain(protectingyourPAspeakers).

PHASE REVERSE

Reversing the phase can help eliminate unwanted frequencies that may result in feedback

orsimplyhelpcorrectthesoundwhenitsounds‘outofphase’ornotquiteright.

HI-Z (Only available on CH1 and CH2)

Highvoltage,Lowcurrentsourceslikeguitars,keyboardsandbasseswillbenetfromusing

the Hi-Z input on CH1 and CH2.

INPUT DELAY

The Input delay can be varied from 1-250ms. This will enable the user to allow for different

microphone placements on a large stage for example. By delaying the input signals form

various sources, the user can create a more coherent mix.

Enter the GAIN tab. Each input fader bay will offer a delay button. When pressed a delay

entry modal will open allowing user input of selected delay value.

The user enters a delay value in ms, meters, ft, or samples.

ISOLATE

Isolate channel parameters from changing with show or snapshot revisions. This protects

the parameter from being overridden by snapshot changes.
