4.2.4: METERS
4.2.4: METERS
Ui24R User Manual
METERS
The Meters page displays all active channels meter readings along with indicators for Mute, Solo,
Phantom 48v power and Phase Reverse.
Users can click on any channel meter and they will be brought to directly to that channel. Alterna-
tively, double clicking in an input channel will bring the user back to the Meters page.
Color coded indicators
for 48v Phantom power,
Inverse, Mute and Solo.
At a glance the user can
keep an eye on peak
levels for all channels
