Ui24R User Manual

10.1.3: LAN

SETTINGS > NETWORK CONFIG > LAN

10.1.3: LAN SETTINGS

Use the Save/Update button to save LAN settings.

IMPORTANT:YoumustrecycletheUipower(turntheunitoffandon)forsettingstotakeeffect.

Default Settings

LAN IP: 10.10.2.1

Subnet mask: 255.255.255.0

Direct Connection

MostcomputerswithaGigaBitadapterwillAutoNegotiateandsowhenconnecteddirectlytotheunit(notviaa

switch)therewillbenoneedforanEthernetcrossovercable.UseastaticIPforthecomputer,inthesamerange

astheunit,suchas10.10.2.5andentertheIPaddressoftheunitinthecomputer’sbrowser.

TheUicanconnecttoanexistingwiredLAN(LocalAreaNetwork)byconnectiontheEthernetporton

the side of the unit. This is the fastest, most secure method of connection to the Ui. Select the LAN

CongurationmenuinNetworkCongtoedittheLANsettings.

LAN

Enabled / Disabled

EnableordisabletheUi’sEthernetport.

Address

DHCP / Manual

You can choose dynamic IP allocation, in which case the Ui will automatically allocate an IP, Netmask, and Gateway.

IfyouchooseManualIPallocation,youwillneedtocompletetheseeldsyourself.Pleaserefertoyournetwork

administrator for manual IP allocation.
