SoundCraft Ui24R User Manual

Ui24R User Manual
4.0:1 CHANNEL STRIP
CHANNEL STRIP
4.0:1 CHANNEL STRIP
TheChannelStriphasahostofinformationrightatyourngertips.Thefollowingisabreakdownof
whatausercanexpecttond.
VCA and Subgroup
indicators are displayed in
bottom RH corner when
activated.
When channel mute is
activated the gain meter is
displayed in blue.
Mute and Solo buttons when acti-
vated will either Mute the channel,
removing it from the mix or Solo it
by removing all other channels.
Channel Gain LED
indicators display gain
level. Peak levels are
displayed in Red.
Channels can be named
by double-clicking on
the channel number
VCA group information
is displayed top LH for
multiple VCA groupings
Stereo pairing when
activated will pair two
adjacent channels and
pan them left/right

SoundCraft Ui24R Specifications

General

Channels quantity	24 channels
Digital sound processing	- bit
Microphone in	Yes
Master (XLR) out	8
Line inputs (RCA)	1
Headphone connectivity	6.3 mm
Number of microphone inputs	10
Rack capacity	4U
Video capability	-
USB connector type	USB Type-A, USB Type-B
LED indicators	Wi-Fi
Built-in display	No

Weight and Dimensions

Package weight	13600 g
