4.0: MIXER CHANNELS

MIXER CHANNELS

4.0: MIXER CHANNELS

The Ui mixers has a variety of input and output channel types. You can view all channels in the main

MIX screen and drag-scrolling along the virtual console. You can also use the MIX page Slideout

panelstoselectspecicchanneltypesandpresetviews.

INPUT CHANNEL - sections 4.1 and 4.2

AUiInputchannelconsistsofaGAINsection(physicalinput,pre-amp,phase,phantompoweretc)andthe

MIXsection.Inputchannelsfeedthemainstereobus(totheMasterChannel),theauxsendbusses(totheAux

Masterchannels),andtheFXsendbusses(andontotheFXReturns).Aninputchannel’scontributiontothese

bussesiscontrolledontherelevantsoftwarepage,orinthechannel’sEDITscreen.

AUX SENDS / AUX MASTER CHANNEL - section 4.3

AuxOutputs(shortforAuxiliary)aretheoutputsonthetoprightoftheUihardware.Theseoutputseachhave

their own mix of input sources, separate from the master mix. Generally, aux outputs are used for musicians to

heartheirownmixonstageviaastagemonitorspeakerortoheadphoneampliersforin-earmonitoring.

Alternatively, the aux outputs can be sent to external hardware FX units.

SUB GROUP MASTER CHANNEL - section 4.5

If you want to have individual control over the drum kit mix components, for example, but also want single fader

controloverthewholekit’scontributiontothemix,youwoulduseaSubGroup.

FX SENDS / FX RETURN CHANNEL - section 4.4

FX SENDS faders effectively determine the amount of effect on each input channel. They work much like aux

sends in that a mix of input channel contributions is created on the FX SENDS page - one for each FX

processor.

MASTER CHANNEL - section 4.6

TheMasterStereoChannelistheoutputchannelforthemainstereo(left&right)mix-determinedbytheinput

channel and FX Return channel faders and pan/balance controls.
