1.3: SPECIFICATIONS
INTRODUCTION > SAFETY
1.3: SPECIFICATIONS
Ui24R User Manual
SOUNDCRAFT Ui TYPICAL SPECIFICATIONS
• Frequency Response
20Hz-20kHz +/- 0.5 dB
• THD
Mic
input(Mingaintobus)@1kHz<0.005%
Mic
input(Maxgaintobus)@1kHz<0.008%
• Noise
Residual Noise -96dBu
Mic Input E
.I.N.22Hz-22kHz unweighted:
-128dB EIN
• Input Gain
Mic/Line
Gain-6dBto+58dB(Stepaccuracy
dependsonsizeoffaderinGUI)
• Gate
Threshold -inf to +6dB
Attack 1ms to 400ms
Release 5ms to 2000ms
Hold 1ms to 2000ms
Depth -inf to 0dB
• Compressor
Threshold -90dB +6dB
Ratio 1:1 - 50:1
Attack 1ms - 400ms
Release 10ms - 2000ms
Makeup Gain -24dB - +48dB
• EQ Channel
4 band parametriq EQ
Each Band Freq 20Hz to 22kHz
Q .05 - 15
Gain -20dB to +20dB
HPF
20Hzto1kHz(selectableslopes)
LPF
22kHzto1kHz(selectableslopes)
• De-esser
Threshold -90dB to 6dB
Ratio
innityto1:1
Frequency 2kHz to 15kHz
• EQ Outputs
31 band GEQ, 20Hz - 20KHz +-15dB
• Compressor outputs
Threshold -90dB +6dB
Ratio 1:1 - 50:1
Attack 1ms - 400ms
Release 10ms - 2000ms
Makeup Gain -24dB - +48dB
• dbx®
AFS on all outputs
12
parametricEQ’
s
(6xed,6oating)
• Latency
All Processing ON for inputs and outputs 3.2ms
• Input and Output Levels
Mic Input +19.5dBu max
Line input +19.5dBu max
Mix output +20.5dBu max
Headphone outputs 500mW 1 output used
(@120Ω),
380mwbothoutputsused
• Input and Output Impedances
Mic
input1-24.2kΩinput3-206kΩ
Line
Input12kΩ
Hi-Z
Input>600kΩ
Balanced
Outputs<150Ω
• USB
Max Current 500mA
Max Current available to all ports: 900mA
• Power
Consumption
(typical)<65W
AC input voltage range 88-265V
AC auto sensing
AC frequency 47-63Hz
• Operating Conditions
Temperature range 5°C - 40°C
Humidity0%-90%
Storage T
emperature -20°C to 60°C
E & OE.Soundcraft reserves the right to change
specicationsandorimagesinthismanualwith-
out notice.
