SoundCraft Ui24R User Manual

3.1.1: CONTROL / GESTURE SUMMARY
SOFTWARE > CONTROL SUMMARY:CHANNEL EDIT PAGE GRAPHIC EQ
3.1.1: CONTROL SUMMARY
Ui24R User Manual
On Master EQ and AUX1-2 you
may also DRAG HPF and LPF
EQ’s to select the desired fre-
quency.
Note, only available on MASTER
Left/Right and AUX/MATRIX 1 and
2.
GEQ frequency to adjust dB gain of selected fre-
quency.
Double click/tap GEQ frequency to reset selected frequency to 0dB.
Drag GEQ to see the rest of the
frequencies (size depends on
screen size being used)
Top Left hand corner you will see a
representation of all 31 bands

SoundCraft Ui24R Specifications

General

Channels quantity	24 channels
Digital sound processing	- bit
Microphone in	Yes
Master (XLR) out	8
Line inputs (RCA)	1
Headphone connectivity	6.3 mm
Number of microphone inputs	10
Rack capacity	4U
Video capability	-
USB connector type	USB Type-A, USB Type-B
LED indicators	Wi-Fi
Built-in display	No

Weight and Dimensions

Package weight	13600 g
