3.2.1: KEYBOARD CONTROL
SOFTWARE > GUI shortcuts
3.2.1: KEYBOARD CONTROL
Ui24R User Manual
Nav bar LCD - long click to jump to SETTINGS->SHOWS
Master channel strip LCD - click to toggle view between MIX and METERS page
Pan slider - single click to show value in LCD
Pan slider - Double click to reset to CENTER
Fader cap - Double click fader cap to jumpt to EDIT->GEQ
Fader cap if MASTER LOCK ENABLED and HOLD FADER FOR FINE TUNING ON in Settings:
- Long click 2 sec to temporarily unlock and adjust fader value
-Longclick4sectoHOLDFADERFORFINETUNING(ifmasterlockinnotON,HOLDFADERFOR
FINETUNINGissetto2seconds)
Channel label - long click to enable channel pop menu
Meters page
Channel meters - click to select channel and jump to MIX page
Free space in METERS->MUTES/VIEWS/SUBS/VCA - Double click in free speace to return to MIX page
MIX page
Channel Strip
Channel LCD - Double click to reset to 0dB
Channel LCD - Long click to manually enter value
Pan slider - single click to show value in LCD
Pan slider - Double click to reset to CENTER
Channel strip Inputs/LINE/SUB GROUPS - Double click strip/VU zone to go to Meters
Channel strip PLAYER - Double click to go to Player page
Channel strip FX Master strip zone - Double click to go to FX Sends
Channel strip AUX Masters - Double click to go to AUX Sends
Fadercaps-DoubleclickfadercapstojumpttoEDIT->EQ(exceptVCA)
Channel labels - long click to enable channel pop menu
Channellabels-doubleclicktojumptoEDIT->COMP(excludesFXMasters)
Channel labels FX Masters - double click to jump to EDIT->FX SENDS
EDIT PAGE
Generally double clicking in free space will return the user to the MIX page
AUX Sends
Tab key to toggle through AUX Master channels
Channel strip zones - Double click to go to Mix page
FX Sends
Tab key to toggle through FX Master channels
Channel strip zones - Double click to go to Mix page
Small Slide Out
Sub group button - Long click to jumpt to METERS->SUBS
View group button - Long click to jump to METERS->VIEWS
Mute group button - Long click to jump to METERS->MUTES
Tap Tempo button - Long click to manuall enter Tempo
Big Slide Out
Mute group buttons - Long click to jump to METERS->MUTES of the currently selected group
View Group buttons - Long click to jump to METERS->VIEWS of the currently selected group
Tap Tempo button - Long click to manuall enter Tempo value
Generally double clicking in free space will return the user to the MIX page
Tap tempo button - long click to enter manual value
