1.0: INTRODUCTION
INTRODUCTION TO Ui
1.0: INTRODUCTION TO Ui
The Ui Series mixers feature cross-platform compatibility with iOS, Android, Windows, Mac OS, and
Linux devices, and can use up to 10 control devices simultaneously. In addition, the Ui24R features
built-in HARMAN signal processing from dbx, DigiTech and Lexicon, including dbx AFS
2
, DigiTech
Amp Modeling, and more. The Ui24R features fully recallable and remote-controlled mic pre-amps and
phantom power designed by Studer.
MAIN FEATURES
•Tablet/PC/SmartphoneControlledDigitalMixer
•IntegratedDualAntenna2.4Gand5GWi-FiandLANconnection
•Cross-platformcompatibilitywithiOS,Android,Windows,MacOS,andLinuxdevices
•Useupto10controldevices(tablets,phones,PCs)simultaneously
•LegendaryHarmanSignalProcessingfromdbx®,Digitech®,andLexicon®
•Fullyrecallableandremote-controlledmicpreamps
•4-bandParametricEQ,High-PassFilte,Low-PassFilerr,Compressor,De-esserandNoiseGateoninputchannels
•31-bandGraphicEQ,NoiseGateandCompressoronalloutputs(MasterL/RandAUX1/2featureLPFancdHPFlters)
•Real-TimeFrequencyAnalyser(RTA)oninputsandoutputs
•4dedicatedLexicon®FXeffectsprocessors:Reverbs,Delays,Chorus
•4xSubgroups,6xVCA’s,MuteGroups,ViewGroups,andMOREMEmixercontrols
•Show/Snapshotrecallwithchannelsafesandsecuritylockout
•2-channelUSBaudioplaybackandrecordingand22multi-trackUSBrecording
•32x32USBAudioInterface
•IntergratedswitchmodeIECconnectionpowersupply
Ui24R User Manual
The Ui24R boasts 22 mic/line inputs, 10 x XLR combo mic/line inputs, 10 x XLR mic inputs, two channels of
Hi-Z/instrument inputs, as well as a stereo RCA line input. A 2-channel USB media player is included, along
with eight balanced XLR Aux/Matrix outputs, two quarter-inch headphone outputs with level control, plus
balanced stereo XLR and quarter-inch main outputs. Two-channel USB audio playback is compatible with
MP3, WAV and AIFF formats. It also includes a 22 multi-track recorder/player, 32 x 32 low latency audio
interface and direct HDMI display connection output.
